GD32VW553系列
-
概述
-
产品组合
-
产品选择器
-
文档
概述
GD32VW553系列MCU支持Wi-Fi 6及Bluetooth LE 5.2无线毗连。GD32VW553系列MCU集成的2.4GHz Wi-Fi 6射频模块接纳IEEE 802.11ax标准 ，并向下兼容IEEE 802.11b/g/n标准 ，可以适用于差别的网络情形。片上集成的Bluetooth LE 5.2射频模块 ，能够以最新的蓝牙规范延伸通讯距离、提高吞吐量、增强清静性和节约电能。面向实时处置惩罚和高效通讯需求 ，GD32VW553系列MCU接纳了全新的开源指令集架构RISC-V处置惩罚器内核 ，主频可达160MHz。GD32VW553系列集成磷七达4MB Flash及320KB SRAM ，尚有32KB可设置指令高速缓存(I-Cache) ，大幅提升了CPU处置惩罚效率。不但具备精彩的无线性能 ，芯片还设置了富厚的通用有线接口。GD32VW553还具备多重清静特征以简化高性能无线装备的清静毗连和管理 ，从而进一步提升系统清静强度。供电电压1.8V~3.6V ，并提供了85℃~105℃宽温选择 ，以知足工控互联、照明装备以及插座面板等高温场景应用所需。
探索我们的产品组合
-
支持Wi-Fi 6和Bluetooth LE 5.2无线毗连协议
接纳RISC-V内核, 主频高达160MHz
存储容量支持4MB Flash以及320KB SRAM
产品选择器
8条效果
|
Part No.
|
Core
|
Series
|
Package
QFN40
QFN32
|
Max Speed (MHz)
|
Flash (Bytes)
2048K
4096K
|
SRAM (Bytes)
|
I/O
up to 28
up to 21
|
GPTM (32bit)
|
GPTM (16bit)
|
Advanced TM (16bit)
|
HRTM
|
Basic TM (64bit)
|
Basic TM (32bit)
|
Basic TM (16bit)
|
LPTM (32bit)
|
LPTM (16bit)
|
SysTick (64bit)
|
SysTick (24bit)
|
WDG
|
RTC
|
USART+UART
|
LPUART
|
I2C
|
QSPI
|
SPI
|
I2S
|
CAN 2.0B
|
USB 2.0
|
Ethernet
|
SDIO
|
EtherCAT Slave Controller
|
MFCOM
|
LIN
|
LCD-TFT
|
Segment LCD
|
Camera
|
IPA
|
SAI
|
TMU
|
EXMC
|
CEC
|
14bit ADC Units (CHs)
|
12bit ADC Units (CHs)
|
12bit DAC Units
|
Comp
|
IEEE 802.11
|
Bluetooth
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| RISC-V | GD32VW553 | QFN32 | 160 | 2048K | 320K | up to 21 | 2 | 2 | 1 | 0 | 0 | 0 | 1 | 0 | 0 | 1 | 0 | 2 | 1 | 1+2 | 0 | 2 | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 0 | (b/g/n/ax) HT20 | BLE 5.2 | |
| RISC-V | GD32VW553 | QFN32 | 160 | 4096K | 320K | up to 21 | 2 | 2 | 1 | 0 | 0 | 0 | 1 | 0 | 0 | 1 | 0 | 2 | 1 | 1+2 | 0 | 2 | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 0 | (b/g/n/ax) HT20 | BLE 5.2 | |
| RISC-V | GD32VW553 | QFN40 | 160 | 2048K | 320K | up to 28 | 2 | 2 | 1 | 0 | 0 | 0 | 1 | 0 | 0 | 1 | 0 | 2 | 1 | 1+2 | 0 | 2 | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 0 | (b/g/n/ax) HT20 | BLE 5.2 | |
| RISC-V | GD32VW553 | QFN40 | 160 | 4096K | 320K | up to 28 | 2 | 2 | 1 | 0 | 0 | 0 | 1 | 0 | 0 | 1 | 0 | 2 | 1 | 1+2 | 0 | 2 | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 0 | (b/g/n/ax) HT20 | BLE 5.2 | |
| RISC-V | GD32VW553 | QFN32 | 160 | 2048K | 320K | up to 21 | 2 | 2 | 1 | 0 | 0 | 0 | 1 | 0 | 0 | 1 | 0 | 2 | 1 | 1+2 | 0 | 2 | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 0 | (b/g/n/ax) HT20 | BLE 5.2 | |
| RISC-V | GD32VW553 | QFN32 | 160 | 4096K | 320K | up to 21 | 2 | 2 | 1 | 0 | 0 | 0 | 1 | 0 | 0 | 1 | 0 | 2 | 1 | 1+2 | 0 | 2 | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 0 | (b/g/n/ax) HT20 | BLE 5.2 | |
| RISC-V | GD32VW553 | QFN40 | 160 | 2048K | 320K | up to 28 | 2 | 2 | 1 | 0 | 0 | 0 | 1 | 0 | 0 | 1 | 0 | 2 | 1 | 1+2 | 0 | 2 | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 0 | (b/g/n/ax) HT20 | BLE 5.2 | |
| RISC-V | GD32VW553 | QFN40 | 160 | 4096K | 320K | up to 28 | 2 | 2 | 1 | 0 | 0 | 0 | 1 | 0 | 0 | 1 | 0 | 2 | 1 | 1+2 | 0 | 2 | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 1(9) | 0 | 0 | (b/g/n/ax) HT20 | BLE 5.2 |
手艺文档
搜索
-
数据手册（1）
-
用户手册（1）
-
应用条记（34）
名称
EN
CN
宣布时间
-
2024-07-11
-
2023-12-30
-
2023-12-30
-
2023-12-30
-
2023-12-30
-
2023-12-30
-
2023-12-30
-
2023-12-30
-
2023-12-30
-
2023-12-30
-
2023-08-28
-
2023-08-28
-
2023-08-28
-
2024-06-04
-
2024-12-20
-
2023-08-28
-
2023-08-28
-
2023-08-28
-
2023-08-28
-
2023-08-28
-
2023-08-28
-
2023-08-28
-
2023-08-28
-
2022-12-08
-
2022-12-08
-
2022-12-08
-
2022-12-08
-
2022-12-08
-
2022-12-08
-
2022-12-08
-
2022-04-21
-
2022-04-21
-
2022-04-21
-
2024-11-25
